Ad information
Impendence: 4ohm
Efficency: 86DB/SPL
Power Handling:
500w Peak Power
250w Continuous Program Power
Price of $199 is nett.
Price excludes box, any cabling.
Additional $50/- for subwoofer box.
Additional $50/- for cabling & labour if required.
Call us now or visit our website for more details!
Website: http://www.eclipseauto.com.sg/
Ad information
Impendence: 4ohm
Efficency: 86DB/SPL
Power Handling:
500w Peak Power
250w Continuous Program Power
Price of $199 is nett.
Price excludes box, any cabling.
Additional $50/- for subwoofer box.
Additional $50/- for cabling & labour if required.
Merchant information
Features & specs
Rockford Fosgate P1 12” is the first in a family of famous “Punch” subwoofers. The P1S4-12 features a 4-Ohm voice coil, 250 Watts RMS power handling, and can accommodate a grille insert using the included soft touch ABS trim ring.
Features
- Custom 10-AWG nickel plated push terminals
- High density poly-foam surround
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Linear spider with embedded 16 AWG tinsel leads
- Parabolic injection molded ABS/Acrylic dustcap
- Protective PVC textured magnet cover
- Reversable ABS trim ring
- Thermoformed polypropylene cone
Specifications
- CEA-2031 Compliant: Yes
- Size: 12"
- Nominal Impedance: 4-Ohm
- Power Handling:
- 150 Watts RMS
- 300 Watts Max
- Voice Coil Diameter: 1.5" 6-Layer (3.81 cm)
- Magnet Weight: 40 oz.
- Speaker Connector: Dual 10 AWG compression
- Fs (Hz): 25
- Re (Ohms): 3.40
- Le (mH): 3.9
- Qms: 7.30
- Qes: 0.58
- Qts: 0.54
- Vas (Liters): 109.0
- Sd (cm²): 540
- SPL (dB @ 1w/1m): 86
- Xmax (mm): 9.0
- Woofer Displacement: 0.048 cu. Ft. (1.36 Liters)
- Cutout Diameter: 11.125 in. (28.26 cm)
- Mounting Depth: 5.875 in. (14.92cm)
- Weight: 12.50 Lbs. (5.67 Kg.)
