Rockford Fosgate P1S4-12 12" 150 Watt Subwoofer
$199
Condition
Brand New
Suitable For
All Models
Posted on: 26 Sep 2021 | Updated on : 26 Sep 2021

Merchant information

155 Kaki Bukit Avenue 1 #01-00 Shun Li Industrial Park S(416012)
10am - 10pm (Mon - Fri) 10am - 9pm (Sat)
68442814
92376217

Ad information

Impendence: 4ohm

Efficency: 86DB/SPL

Power Handling:

500w Peak Power

250w Continuous Program Power


Price of $199 is nett.

Price excludes box, any cabling.


Additional $50/- for subwoofer box.

Additional $50/- for cabling & labour if required.

Call us now or visit our website for more details!

Website: http://www.eclipseauto.com.sg/


Ad information

Impendence: 4ohm

Efficency: 86DB/SPL

Power Handling:

500w Peak Power

250w Continuous Program Power


Price of $199 is nett.

Price excludes box, any cabling.


Additional $50/- for subwoofer box.

Additional $50/- for cabling & labour if required.

Merchant information

155 Kaki Bukit Avenue 1 #01-00 Shun Li Industrial Park S(416012)
10am - 10pm (Mon - Fri) 10am - 9pm (Sat)
68442814 / 92376217
Posted on: 26 Sep 2021 | Updated on : 26 Sep 2021

Features & specs

Rockford Fosgate P1 12” is the first in a family of famous “Punch” subwoofers. The P1S4-12 features a 4-Ohm voice coil, 250 Watts RMS power handling, and can accommodate a grille insert using the included soft touch ABS trim ring.

Features

  • Custom 10-AWG nickel plated push terminals
  • High density poly-foam surround
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Linear spider with embedded 16 AWG tinsel leads
  • Parabolic injection molded ABS/Acrylic dustcap
  • Protective PVC textured magnet cover
  • Reversable ABS trim ring
  • Thermoformed polypropylene cone

Specifications

  • CEA-2031 Compliant: Yes
  • Size: 12"
  • Nominal Impedance: 4-Ohm
  • Power Handling:
  • 150 Watts RMS
  • 300 Watts Max
  • Voice Coil Diameter: 1.5" 6-Layer (3.81 cm)
  • Magnet Weight: 40 oz.
  • Speaker Connector: Dual 10 AWG compression
  • Fs (Hz): 25
  • Re (Ohms): 3.40
  • Le (mH): 3.9
  • Qms: 7.30
  • Qes: 0.58
  • Qts: 0.54
  • Vas (Liters): 109.0
  • Sd (cm²): 540
  • SPL (dB @ 1w/1m): 86
  • Xmax (mm): 9.0
  • Woofer Displacement: 0.048 cu. Ft. (1.36 Liters)
  • Cutout Diameter: 11.125 in. (28.26 cm)
  • Mounting Depth: 5.875 in. (14.92cm)
  • Weight: 12.50 Lbs. (5.67 Kg.)
Consumer Reviews
The Rockford Fosgate Punch series of car subwoofers are great if you want a thunderous, punchy low-end to your car audio. This makes it ideal for listening to hip-hop and heavy metal. The continuous and peak power handling provides you plenty of room to push the speakers with a power amp, which you'll need because of the inefficient 86dB sensitivity rating.
Reviewed by CloudStrifeX
